Apex Security · 2026
Wearable technology combining IoT sensors, health monitoring, and real-time hazard detection to protect workers in dangerous environments.
Accident
Prevention
Battery
Life
Response
Time
Comprehensive protection through intelligent monitoring systems for the modern industrial workforce.
Custom probes detect live conductors up to 5 m away, preventing electrical accidents before contact.
EF Sensor · GPIO ADCMLX90614 IR sensors scan for hot surfaces and overheating equipment at 10 Hz continuously.
MLX90614 · I2C · 0x5AHeart rate and SpO₂ via MAX30102. Alerts fire if values leave safe thresholds.
MAX30102 · I2C · 0x57MPU6050 detects free-fall and impact, dispatching SOS after a 15-second confirmation window.
MPU6050 · I2C · 0x68Haptic, buzzer, and LED channels fire across three priority levels simultaneously.
Haptic · Buzzer · LEDBLE 5.0 for wrist-cuff telemetry and 802.11n WiFi for cloud dashboard sync via MQTT.
ESP32-S3 · BLE · WiFi| Component | Part | Interface | Notes |
|---|---|---|---|
| Processor | ESP32-S3 | Core MCU | Dual-core LX7, BLE + WiFi |
| Thermal | MLX90614 | I2C · 0x5A | HW-691 breakout |
| Pulse Oximeter | MAX30102 | I2C · 0x57 | SpO₂ + Heart Rate |
| IMU | MPU6050 | I2C · 0x68 | 6-axis motion |
| Proximity | IR Module | Digital · GPIO34 | FC-51 / TCRT5000 |
| Light | LDR | ADC · GPIO35 | 10 kΩ divider |
| Battery | 18650 Li-ion | 3.7V | 72h continuous |
| Charging | USB-B | 5V / 2A | Programming + charge |
| Op. Temp. | −40° to 85°C | Ambient | Industrial, IP44 |
| Alert Output | Haptic + LED | GPIO PWM | 3-channel |
